Foundation Contractor Norwich
KiKK Groundworks installs foundations across all of Norwich for house extensions, new builds, conservatories and commercial projects. Every job is specified to your actual ground conditions. Norwich City Council Building Control managed throughout.
100+ Happy Customers
Norwich has some of the most varied ground conditions of any city in East Anglia and most homeowners planning an extension have no idea until the digger goes in.
The clay in Eaton, Lakenham and parts of south-west Norwich is heavy and reactive. It shrinks significantly in dry summers and swells back in wet winters. On this ground, standard-depth strip foundations create problems within a few years; the seasonal movement works on the foundation walls and shows up as diagonal cracking above window and door openings in the extension above.
Move to Sprowston, Thorpe St Andrew or parts of Hellesdon and the picture changes. The sandy fill that underlies much of east Norwich behaves very differently from Eaton clay; it is more stable seasonally but has lower bearing capacity, which affects the foundation width and depth calculation.
Then there are the older properties in NR2 and NR3. Victorian Norwich was built on made ground of highly variable composition. When you open a trench on a pre-1920 property in the NR2 or NR3 postcode, you genuinely do not know what you will find at 600mm. Unmapped drainage runs, buried brickwork, ash fill, and occasionally the foundations of structures that were demolished and forgotten about.
KiKK has worked across all of it. Kallan Martin has installed foundations in Eaton, Sprowston, Thorpe St Andrew, Hellesdon, Costessey, Mile Cross and across the city centre NR postcodes. He knows what Norwich ground does and how to build foundations that last in it.
KiKK has installed foundations in Eaton clay, Sprowston sandy fill, NR3 made ground and the variable substrates across older Norwich housing stock. Ten years of opening trenches across specific Norwich postcodes.
Full public liability insurance and compliance with all current Building Regulations. Complete documentation for your records and mortgage lender.
From initial notification through to final inspection sign-off, KiKK manages Norwich City Council Building Control directly. Inspections are booked, documentation is prepared, and concrete pours are timed to avoid delays.
On older Norwich properties in NR2 and NR3, trenches regularly produce surprises. KiKK stops, photographs, calls you, and agrees a solution before doing anything else. Nothing gets built over without your knowledge.
Kallan is on site personally for every foundation pour. No project managers, no subcontractors. The person who quoted the job runs the job.
No-obligation site visits with honest, detailed advice. We will tell you exactly what foundation type you need and what it will cost. No surprises on the invoice.
Different buildings, soil conditions and structural requirements call for different foundation types. KiKK installs all major foundation types used in residential and commercial construction across Norwich.
Strip foundations suit Norwich sites where the ground is stable, the bearing capacity is adequate, and the soil type is not heavily clay-dominated. In practice, this means parts of east Norwich, Sprowston, Thorpe St Andrew and Blofield, where sandy or gravelly ground gives consistent load-bearing properties.
On these sites, a properly specified strip foundation at the right depth is cost-effective and perfectly appropriate. Building Control Norwich is straightforward to satisfy with the standard documentation.
Where strip foundations become the wrong choice in Norwich is on the clay-heavy ground in Eaton, Lakenham and Unthank. Here, the seasonal shrink-swell movement that Norfolk clay is known for acts directly on the concrete and brickwork above. Under-specified strip foundations on Norwich clay are one of the most common causes of extension movement cracking we see when clients call us to assess existing buildings.
Trench fill is the foundation type KiKK specifies most often on Norwich clay sites. The entire trench is filled with concrete to near ground level, removing the cavity that allows soil movement to act on the foundation structure.
It uses more concrete. It is faster on site. And on the clay ground that covers a large portion of Norwich's residential areas, it is what Norwich City Council Building Control expects to see, particularly for extensions on NR4 and NR1 addresses in clay-heavy ground.
A single-storey extension on Norwich clay, specified to trench fill at appropriate depth, typically costs £5,500 to £10,000 for the foundation package. Kallan will confirm the specification and price at the site visit, not before, because the ground condition on your specific plot is the deciding factor.
Raft foundations distribute load across a wide reinforced concrete slab rather than concentrating it in strips. In Norwich, they come up most often on:
Raft foundations in Norwich run £9,000 to £20,000 for a residential extension depending on slab dimensions and reinforcement. When the ground requires a raft, the cost of not building one correctly is always higher. KiKK has seen what happens when rafts are underspecified on Norwich made ground.
Conservatory bases in Norwich follow the same ground logic as extension foundations. On clay ground in Eaton and south Norwich, a proper depth and specification is not optional. The seasonal movement that breaks under-specified extension foundations will break a conservatory base even faster, because conservatory glazing tolerates movement less well than brickwork.
KiKK installs conservatory and garden room bases to full Building Control specification across Norwich. Every base includes excavation to appropriate depth, compacted sub-base, DPC and oversite concrete. On clay, we go below the shrink-swell zone. This is not the cheapest option. It is the one that does not fail.
Pad foundations are isolated concrete bases used to support point loads, typically from steel or timber columns. They are common in commercial and industrial construction, steel-framed buildings, and domestic projects such as oak-framed garages, car ports and pergolas across Norwich.
KiKK constructs pad foundations for steel portal frame buildings, agricultural structures, and residential oak-frame projects across the Norwich area.
Choosing the right foundation type depends on your ground conditions, building type, budget, and structural engineer's recommendations. Here is a side-by-side comparison of the three most common foundation types used in Norwich:
| Feature | Strip Foundations | Trench Fill | Raft Foundations |
|---|---|---|---|
| Typical Depth | 1.0 to 1.5m | 1.0 to 1.5m | 200 to 300mm slab |
| Concrete Volume | Lower | Higher | Highest |
| Labour Intensity | High (blockwork needed) | Low | Medium |
| Speed of Construction | 2 to 4 days | 1 to 2 days | 2 to 3 days |
| Best Soil Types | Sandy, gravelly (Sprowston, Thorpe) | Clay (Eaton, Lakenham, Unthank) | Made ground (NR2, NR3), soft |
| Reinforcement | Usually not required | Usually not required | Always required (mesh and bars) |
| Typical Cost (extension) | £4,000 to £8,000 | £5,500 to £10,000 | £9,000 to £20,000 |
| Building Control | Trench inspection required | Trench inspection required | Slab inspection required |
| Common Use in Norwich | East Norwich, garages | Clay sites, most domestic projects | Wensum, Yare areas, NR2 and NR3 |
Foundation work for any extension or new build in Norwich requires Building Control approval. In Norwich, this means working with Norwich City Council Building Control, which operates through the CNC Building Control partnership.
KiKK manages the full process directly: initial notification, foundation inspection booking, and all documentation required at each stage. You do not need to contact Building Control yourself or understand the notification procedure. We handle it as part of the job.
For foundation work specifically, the Building Control inspector visits once the trench is excavated to check depth and soil conditions before concrete is poured. This inspection cannot be skipped. KiKK coordinates the timing of this visit around the concrete delivery so there is no unnecessary delay between inspection and pour.
If your project also requires a structural engineer's input, for larger extensions, unusual loading or complex geometry, KiKK can recommend engineers who work regularly across Norwich and understand the city's ground conditions. A structural engineer based in Norwich costs less time and fewer misunderstandings than one who has to learn the local soil conditions from scratch on your project.
Kallan will visit your Norwich site, look at the ground, and provide a written quote. Norwich ground varies too much for phone estimates to mean anything.
KiKK installs foundations across the full Norwich area with no call-out charge within our standard service zone.
City and inner suburbs: NR1 · NR2 · NR3 · NR4 · NR5 · NR6 · NR7
Outer Norwich and surrounding: Poringland NR14 · Hethersett NR9 · Cringleford NR4 · Wymondham NR18 · Long Stratton NR15 · Blofield NR13 · Aylsham NR11 · Wroxham NR12
Call 01603 381016 if you are unsure whether your postcode is covered.
Google Reviews
4.7
14 Google reviews
KiKK Groundworks
Google Business
Existing foundation concerns?
Compare traditional foundation support with resin ground treatment, including the potential for re-levelling where conditions allow. The right method depends on the building and the ground assessment.
FAQ
Eaton and Lakenham clay typically needs 750mm to 1 metre. Sandy ground in Sprowston and Thorpe St Andrew is assessed differently. NR2 and NR3 made ground requires site investigation before any depth is confirmed. KiKK assesses every plot individually at the site visit.
Norwich City Council, through the CNC Building Control partnership. KiKK manages all notifications, inspections and documentation directly. You do not need to contact them yourself or understand the notification procedure.
Not always. Simple single-storey extensions on standard ground can proceed to Building Control minimums without an engineer. Larger projects, steel frames or unusual ground conditions benefit from engineer input. KiKK will advise at the site visit and can recommend engineers who work regularly across Norwich.
Trench fill fills the entire excavated trench with concrete to near ground level. On Norwich clay, which shrinks in summer and swells in winter, it removes the cavity that allows soil movement to damage foundation walls. It is faster to construct and more appropriate than strip foundations on clay sites.
Strip foundations run £4,000 to £8,000. Trench fill on clay costs £5,500 to £10,000. Raft foundations run £9,000 to £20,000. All prices depend on depth, access and ground conditions found on your specific plot. KiKK provides a written quote after a site visit, not a phone estimate.
Two to four days on site for a standard single-storey extension. Add seven days minimum for concrete to reach working strength before building work continues. Deeper or more complex packages run five to ten days on site.
